5
OPERATINGINSTRUCTIONS
Triangular
Wheel Stops
Rear Wheel
Chock
Fig. 1
Fig. 2
LOWER TO LOCKS
LIFT ON
LOCKS
WHEN LIT
Control Fault
Beeper
Raise Button
Lower Button
Lower To Locks Button
(Blinks When Lift Is Not
Resting On Locks)
Disconnect Switch
Fig. 3
Leg Link
Arm Link
Runway
Hands Clear Warning
NP945 REV.-
