OPERATING INSTRUCTIONS
SURFACE MOUNTED FRAME ENGAGING LIFTS
To avoid personal injury and/or property damage, permit only trained personnel to operate lift.
After reviewing these instructions, get familiar with lift controls by running the lift through a few cycles before loading vehicle on lift.
Always lift the vehicle using all four adapters. NEVER raise just one end, one corner, or one side of vehicle.
Assure vehicle frame can support it's weight & overhead bar or sensor will contact highest point on the vehicle.
1. Before Loading:
• Inspect Lift - See "Operator Inspection And Maintenance" on
page 8. Never operate if lift malfunctions or has broken or
damaged parts.
• Lift must be fully lowered and service bay clear of all
personnel before the vehicle is positioned onto lift.
• Swing arms out to full drive-thru position.
• Assure area around lift is free of tools, debris, grease, and oil.
• Assure Adapter Pads are free from grease and oil.
• Do Not allow unauthorized persons in shop area while lift is in
use.
• Do Not use any part of the lift as a crane or as a support for
another lifting mechanism (i.e.: block & tackle, etc.).
• Turn E-Stop switch to "ON" Position, Fig. 1.
For E series lifts turn both E-Stop switches "ON", Fig. 2.
2. Loading:
• Do Not allow unauthorized or untrained persons to position
vehicle or operate lift.
• Do Not drive over arms.
• Do Not overload lift. See capacity label on lift.
• Use Only adapter extenders provided by the manufacturer.
Do Not use wood, concrete blocks, or other improvised
extenders.
• Spot vehicle over lift with left front wheel in proper spotting
dish position, Fig. 3. Position vehicle according to the center
of gravity, not for door opening clearance.
• Check the condition of the pickup points of the vehicle.
• Swing arms under vehicle and position adapters at vehicle
manufacturer's recommended lift points, Fig. 3. Adjust
adapters to the required height to keep the vehicle level and
properly balanced.
• Use optional adapters for under body clearance when required.
Adapter extensions are furnished in 127mm
and 254mm increments. The stack up height should not exceed
381mm. Use adapter extension combination to keep vehicle as
level as possible while it is being supported by the lift.
3. To Raise Lift:
• Do Not permit anyone on lift or inside vehicle when it is being
raised or lowered.
• Maintain visual contact with arms, pickup points, & vehicle
throughout the motion of the lift while remaining clear of lift.
• For M Series Lifts: Actuate RAISE Switch on Control Box to
raise lift, Fig. 1.
• For E Series Lifts: Push on control panel, Fig. 2.
Note: Allow 2 seconds between motor starts. Failure to comply
may cause motor burnout.
• Stopbeforemakingcontactwithvehicle.Checkarmrestraint
pins for engagement. If required, slightly move arm to allow
restraint gear and pawl to mesh. DO NOT hammer pin down as
this will damage the restraint gear teeth.
To Next Page
