Page | 23 DRM-3000 Operating Manual
1. START SCREEN
Click on the Confirm Button to display the Main Menu
START SCREEN
DETECTOR DETAILS
METER DETAILS
DISPLAY OPTIONS
Q-SETUP
Click on the Up or Down Button to navigate to the required command [START SCREEN]
Click on the Confirm Button and the Sub-Menu will appear
Show/Hide Power Options
In both cases click on the Confirm Button to toggle
between the two options, the Icons will reflect the status.
Show/Hide Comm. Icons
Select Screen
Used to Select (Focus) on a specific screen if more than one
detector is displayed.
Change Brightness 6
Used to change the brightness of the display. Each click on
Confirm Button changes the level of brightness
In the case of more than one external detector connected to the DRM-3000, the user can
select which of the four can be in focus and displayed in a full screen mode. The Focus on
the specific detector is used to enable the user to query and/or modify a parameter. There
are two methods to Focus on a single Display, the first is Q-Focus described below and the
second is menu driven by asking you to select which detector you want to focus on. if you
need to see the details of a specific detector, we suggest you first focus into that detector
and then open the Detector Details Menu. This will save you the extra step of having to
define the position of the detector on the screen after opening the Menu
Q-Focus: Click on the button next to screen. To Focus on the Internal Detector, click on the
Select Button and the Internal Detector will open to full screen. To revert back to the four
screens, click on the Select Button again. In the example below, if you click on the Down
Button you will see a blank screen.
