Installation and user manual
The main/secondary wired controller can be used to enable two wired controllers
to control one unit, and the wired controllers connect to the unit HA and HB ports
through the HA and HB port on the controller. There is no polarity between HA and
HB. SeeFig. 3-8
Fig. 3-8
HA HB
Indoor Unit
Wired Controller
HA HB
HAHB
HAHB
Indoor Unit
Wired Controller 1
Wired Controller 2
