Rothenberger RO - Switching between image types; Image capture; Image output; Menu

ENGLISH
11
11 Menu
Press the “ ” or “ ” key to switch the degree of fusion between infrared
thermal images & visible images (the degree of fusion is 0%, 25%, 50%,
75% & 100%).
Press the image capture trigger. When the capture is successful, the screen
will display “store photo?”. If “yes” is selected, press the “MENU/ ” key to
save the image. If “no” is selected, press the “ SELECT/ENTER ” key to delete
the image.
Press the “ ” key to switch between displaying or hiding the highest &
lowest temperature.
Saved images can be downloaded by connecting a computer through a Micro
USB lead.
*Supported operating systems: all USB 2.0 compliant OS.
Image overlapping makes it easier for users to understand the infrared
images by using aligned visible images & infrared images. The use of image
overlapping can capture the visible image of every infrared image so as to
display the temperature distribution in the target region correctly & share
with other people more effectively.
Press the “MENU/ ” key to access the menu bar.
10.4 Switching between image types
10.5 Image capture
10.6 Hide highest & lowest temperature
10.7 Image output
11.1 Image overlapping sub menu
