Rothenberger RO User Manual

ENGLISH
19
14 EU declaraton of conformity
This declaration of conformity is issued under the sole responsibility of the
manufacturer:-
Kane International Ltd.
Kane House, 11 Bessemer Road, Welwyn Garden City, Hertfordshire. AL7
1GF, UK.
Tel: +44 1707 375550 Web: www.kane.co.uk
The KANE T-CAM is in conformity with the relevant Union harmonization
legislation below:
DIRECTIVE TITLE
201430EU Electromagnetic Compatibility (EMC)
201165EU
Restriction of the use of certain hazardous substances in
electrical and electronic equipment (RoHS)
The following harmonised standards and technical specifications have been
applied:
CERTIFICATION
The KANE T-CAM is tested to the following standards
EMC
EN61326-1:2013
SAFETY
EN61010-1:2010 + A1:2019
ROHS
IEC62321-2:2013, IEC62321-1:2013, IEC62321-3-1:2013, IEC62321-
5:2013, IEC62321-4:2013, IEC62321-7-2:2017, IEC62321-7-1:2015,
IEC62321-6:2015
Signed for on behalf of:- Kane International Ltd.
11 August 2020
Paul Morrison
Engineering Manager

Rothenberger RO Specifications

General

Display screen	2.8-inch full-view TFT display
LCD resolution	320×240
Colour palette	Rainbow, iron oxide red, cold col­ our, black & white, white & black
Temperature measurement range	-20℃ to 300℃ (-4°F to 572°F)
Emissivity	Adjustable from 0.01 to 1.00
Measurement accuracy	±2℃/±2% (whichever is greater)
Infrared image resolution	220×160
Visible image resolution	35200 pixel
Field angle	35°×26°
Focal distance (shortest)	0.15m
Thermal sensitivity	0.07℃
Frame rate of thermal images	9Hz
Focus mode	Fixed
Wavelength coverage	8-14um
Storage capacity	Built-in memory 3GB
File format	JPG
Setting command	Unit, language, date, time, information
Language	English & French
USB	Micro USB 2.0
Power supply	Built-in chargeable 18650 battery Detachable
Automatic power-off time	Selectable: 5 minutes/20 minutes/ not power off automatically
Working time	2-3 hours

Weight and Dimensions

Product size	96mm×72mm×226mm
Product weight	389g
