Rothenberger RO - Display; Colour code; Central point temperature cursor; Highest point temperature cursor

ENGLISH
9
8 Display
Battery
power
Colour code
Time
Central point
temperature
cursor
Lowest
temperature
cursor
Central point
temperature
Maximum value & minimum value of
eld temperature
Highest
temperature
cursor
Current emissivity
Marks the colour corresponding to the relative temperature from low to high.
(See colour palette menu for more details).
Indicates the central position of the screen. The temperature value is also
displayed in the top left corner of the screen.
Indicates the highest temperature position in the screen area. The temperature
value is also displayed in the bottom left corner of the screen.
8.1 Colour code
8.2 Central point temperature cursor
8.3 Highest point temperature cursor
