OPC90 Server
example as
and 3. Th
makes it e
can save th ts
the file for e the
Bailey func his
is the OPC ,
il ding
t ”
setting. Th s an alternative
dir y p ,
OPC90 wil e a
ready exist and are of the format generated
y the ABB Bailey CADEWS software and its derivatives. When the file name is
included in the command, OPC90 will automatically append the “CFG” extension
if it is missing. Including the “CFG” extension in the file name will override the
current FILE_TYPE tag setting. The “CFG” files are also stored in the “ABB”
subdirectory unless an alternative directory path is included as part of the file
name. If the save command is cancelled or it fails, the file will not be generated
and any original file of that name that had been previously saved will remain
unchanged. Following are some example save commands:
Command Action
sume these tags are currently set to the corresponding values of 1, 2
e file name will be “00100203.C90” or “10203.CFG”. This convention
asy to identify what Bailey module the file corresponds with. OPC90
e configuration in one of two file formats. The FILE_TYPE tag selec
mat to utilize. When FILE_TYPE is reset (0), OPC90 will sav
tion block configuration data in files that have a “C90” extension. T
90 file format. When the file name is included in the command
OPC90 w
he “C90
l automatically append the “C90” extension if it is missing. Inclu
extension in the file name will override the current FILE_TYPE tag
e “C90” files are stored in the “ABB” subdirectory unles
ector ath is included as part of the file name. When FILE_TYPE is set (1)
l save the Bailey function block configuration data into files that hav
“CFG” extension. These files must al
b
SAVE Saves currently addressed module.
SAVE MFP01 Saves currently addressed module to a file called “MFP01.C90”.
SAVE MFP01.CFG Saves currently addressed module to a file called “MFP01.CFG”.
SAVE DIGESTER 1 3 5 Saves ring 1 node 3 module 5 to a file called “DIGESTER.C90”.
Load Command
Use this command to load a Bailey module function block configuration from a
previously saved file. Remember the module must first be in configure mode
before it can be loaded with a new configuration. It should also be initialized
before loading the new configuration (see OPERATION command). BASIC
programs or C programs with any associated data files are not included in the
load. Contact RoviSys if your needs include loading of programs. Any file name
can be specified. If the file name includes spaces it must be enclosed in double
quotes. If the file name is excluded, OPC90 will automatically load a file name
based on the current address specified in the ADDR_RING, ADDR_NODE and
ADDR_MODULE tags. For example assume these tags are currently set to the
corresponding values of 1, 4 and 5. The file name that will be loaded is
“00100405.C90” or “10405.CFG”. OPC90 can load the configuration from one of
two file formats. The FILE_TYPE tag selects the file format to utilize. When
FILE_TYPE is reset (0), OPC90 will load Bailey function block configuration data
from files that have a “C90” extension. This is the OPC90 file format. When the
file name is included in the command, OPC90 will automatically append the
“C90” extension if it is missing. Including the “C90” extension in the file name will
override the current FILE_TYPE tag setting. The “C90” files are loaded from the
“ABB” subdirectory unless an alternative directory path is included as part of the
The RoviSys Company Version 7.0 Page 50
