ULTIMATE V-RAKE RMT PARTS LIST
RIGHT WING & LEFT WING
(Left Wing is Mirror Image of Right Wing)
Ref.
Part No. Description Qty.
1 ULT3000R Rear Wing (Specify rake size or Serial #) (Right Wing) 1
ULT3000L Rear Wing (Specify rake size or Serial #) (Left Wing) 1
2 ULT3020R Front Wing (Specify rake size) (Right Wing) 1
ULT3020L Front Wing (Specify rake size) (Left Wing) 1
3 WR6054R Frame, Right Front with bushings (Right Wing) 1
WR6054L Frame, Left Front with bushings (Left Wing) 1
4 ULT3010R Rear Turn Out Extension (Right Wing) 1
ULT3010L Rear Turn Out Extension (Left Wing) 1
5 WR7012 Pin, 2-1/4” x 14” Pivot Joint 1
6 ULT2091 Stabilizer Bar, wing 1
7 ULT5005R Lift Rod Assembly, Rear (Specify rake size) (Right Wing) 1
ULT5005L Lift Rod Assembly, Rear (Specify rake size) (Left Wing) 1
8 ULT5020R Lift Rod, Front (Specify rake size) (Right Wing) 1
ULT5020L Lift Rod, Front (Specify rake size) (Left Wing) 1
9 14344451 Axle, Right Castor 1
14344453 Axle, Left Castor 1
10 12420297 Spindle & Plate, 2” x 7” W888, 6 bolt 2
11 75C300HCS5Z Bolt, 3/4”-10 x 3” HHC G5 4 Std., 2 Opt.
12 75NLOC0Z Washer, 3/4” lock SPT 4 Std., 2 Opt.
13 75CNFH5Z Nut, 3/4”-10 G5 4 Std., 2 Opt.
14 PSW-2202-64BX Bushing, 2-1/2” x 2-1/4” x 3”, Bronze 6 Std., 2 Opt.
15 WR6053 Brake, Disc with bolt & nut, Axle Wheel, 8” 2 Std., 1 Opt.
16 WR4625 Poly Dampener, 1/4” x 5” x 2”, Set of 2 4 Std., 1 Opt.
17 WR4626 Top Plate, Dampener 2 Std., 1 Opt.
18 37C225HCS5Z Bolt, 3/8”-16 x 2-1/4” G5 8 Std., 1 Opt.
19 37CNNE0Z/NE Nut, 3/8”-16 Lock 8 Std., 2 Opt.
20 WR1030 Dampener, Wheel Lock w/ poly assembly 2 Std., 1 Opt.
21 WR5208RMT Stabilizer, Lift Rod Roller Assembly 4
22 WR52081RMT Stabilizer, Bracket, Lift Rod Roller 4
23 WR49241RMT Pin, Stroke Limiter 4
24 100NUSS0Z Washer, 1” at 4
25 PSW-1001-64 Bushing, 1” x 1-1/4” x 1”, Bronze 4
26 R3S-309 Roller, with 1” x 1” Bronze Bushing 4
27 50C125KSQT/CNP Set Screw, 1/2”-13 x 1-1/4” SQ-HD Cone Pt. 4
28 50CNFJ0Z Nut, 1/2”-13 Hex Jam 4
29 WR4925RMT Compression Spring Assembly, RMT Only 4
30 WR4920RMT Rod & Clevis 1 per raking wheel
31 WR4927RMT Boxing, Lift Compression Spring 1 per raking wheel
32 WR4929 Tube & Clevis, Lift Compression Spring 1 per raking wheel
