46
G
ULTIMATE V-RAKE RMT PARTS LIST
RIGHT WING & LEFT WING (Continued)
(Left Wing is Mirror Image of Right Wing)
Ref.
Part No. Description Qty.
33 WR78058 Bushing, 5/8” x 7/8” x 1-1/2” nylon 2 per raking wheel
34 WR4930 Spring Stop, Compression Lift 1 per raking wheel
35 OG-5971 Spring, Lift (.25” x 1.5” x 16”) 1 per raking wheel
36 62CNNE0Z/NE Nut, 5/8”-11 Lock 1 per raking wheel
37 37C200HCS5Z Bolt, 3/8”-16 x 2” HHC G5 1 per raking wheel
38 25CNFH0Z Nut, 1/4”-20 Hex 1 per raking wheel
39 25C75HCS5Z Bolt, 1/4”-20 x 3/4” HHC G5 1 per raking wheel
40 WR4923RMT Guide, Lift Rod, Green Crop 1 per raking wheel
41 WR4924RMT Stop Assembly, Stroke Limiter 1 per raking wheel
41A WR49242RMT Stop Bracket Only, Stroke Limiter 1 per raking wheel
42 9R75PCO0D Cotter Key, 3/32” x 3/4” 1 per raking wheel
43 OG-5145 Spring, Pin Lock 1 per raking wheel
44 WR49241RMT Pin, Stroke Limiter 1 per raking wheel
45 WR4878RMT Holder, Compression Spring, Right RMT 1 per raking wheel
WR4879RMT Holder, Compression Spring, Left RMT 1 per raking wheel
46 37C250HCS5Z Bolt, 3/8”-16 x 2-1/2” HHC G5 1 per raking wheel
47 43CNNE0Z/NE Nut, 7/16”-14 Lock 1 per raking wheel
48 WR7125RMT Rod, Joint Link Lift 1 per raking wheel
49 ULT5205 Linkage, Lift Rod Cylinder 1 per raking wheel
50 107-100 Zerk, 1/4”-28 St Lub 1 per raking wheel
51 WR150130 Spindle, 1-1/2” x 11-1/2” RMT, TAPPED 1 per raking wheel
52 62NUSS0Z Washer, 5/8” USS Flat 1 per raking wheel
53 62NLOC0Z Washer, 5/8” Lock SPT 1
54 62C200HCS8D Bolt, 5/8”-11 x 2” Gr 8 1
55 HD2508 Cylinder, 2-1/2” x 8” 1
56 WR1027 Pin, 1” x 2-3/8” headed 2
57 100N150AMB0/10G Washer, 1” x 1-1/2” x 10Ga AR
100N150AMB0/14G Washer, 1” x 1-1/2” x 14Ga AR
58 18R200PC00Z Cotter Key, 3/16” x 2” 2
59 75C400HCS5Z Bolt, 3/4”-10 x 4” HHC G5 2
60
61 75CNNE0Z/NE Nut, 3/4”-10 Lock 2
62 PSW-1001-64 Bushing, 1” x 1-1/4” x 1” Bronze 2
63 ULT20702 Linkage, Wing Adjustment Cylinder 1
64 845509615T Tire & Rim, 225/75 x 15 with 15 x 6 x 6 front & side 2 Std. 1 Opt.
65 845502225 Tire, ST225/75R15, 4 ply Radial 2 Std., 1 Opt.
66 0411141 Rim, 15 x 6 x 6 bolt 2 Std., 1 Opt.
67 W 888 Hub Only, 6 bolt 2 Std., 1 Opt.
68 CR16289 Seal, 888 hub 2 Std., 1 Opt.
AR=As Required
