ULTIMATE V-RAKE RMT PARTS LIST
RIGHT WING & LEFT WING (Continued)
(Left Wing is Mirror Image of Right Wing)
Ref.
Part No. Description Qty.
69 JL69349 Cone, Inner, 888 hub 2 Std., 1 Opt.
70 JL69310 Cup, Inner, 888 hub 2 Std., 1 Opt.
71 LM67010 Cup, Outer, 888 hub 2 Std., 1 Opt.
72 LM67048 Cone, Outer, 888 hub 2 Std., 1 Opt.
73 9136831 Washer, 888 hub 2 Std., 1 Opt.
74 9129521 Nut, slotted 888 hub 2 Std., 1 Opt.
75 15R125PCO0Z Cotter Key, 5/32” x 1-1/4” 2 Std., 1 Opt.
76 909905 Cap, Dust, 888 hub 2 Std., 1 Opt.
77 0613945 Bolt, 1/2” x 1-1/4” lug, 888 hub 2 Std., 1 Opt.
78 WR71401 Wheel Option, Front Wing Only (Ea.) 1
WR7140 Wheel Option, Front Wing Only (Set of 2) 2
79 ULT2075 Gauge, Position, Lower Pointer 1
80 37C100HCS5Z Bolt, 3/8”-16 x 1” HHC G5 2
81 PM-BHF-3 Cap Vent, 1/2” Cylinder Breather 1
82 ULT3012 Bracket, Tail Light 1
83 62C200HCS5Z Bolt, 5/8”-11 x 2” G5 8 Std. 4 Opt.
84
85 9405-8-8 Street Elbow, 1/2” 90 Deg. w/swivel 1
86 844905120-BX Hydraulic Hose, 1/2” x 120” 2-wire 1
87
88 103-100 Zerk, 1/8” 45 Deg. NPT
89 101-100 Zerk, 1/8”-28 Str. Lub PTF 1
90 50C100HCS8Z Bolt, 1/2” x 1” G8 2
91 50C200HCS5Z Bolt, 1/2”-13 x 2” HHC G5 2
92 50CNNE0Z/NE Nut, 1/2”-13 Lock 2
93 SS-4856-24 Bushing, 1-1/2” x 1-3/4” x 1-1/2” Bronze 2
94 ULT4165 Lift Rod End Adjuster, RMT 1
95 100CNFJ0Z Nut, 1” - 8, Hex Jam 1
96 WR78060 Bushing, Lift Rod RMT 1-2 pc. per raking wheel
97 WR1507RMT Rod Guide Retainer Plate 1 per raking wheel
98 37C100HCS5Z Bolt, 3/8”-16 x 1” HHC G5 4 per raking wheel
99 RM-2115 Pin, 1” x 6-1/2” Hinge Mount 2
100 31R150PSP0/HBK Roll Pin, 5/16” x 1-1/2” Spiral 2
101 845509515 Tire, 9.5L x 15 - 8 ply 2
102 ULT3013 Spacer, Lift Rod Retainer RMT 1
103 845509515T Tire & Rim, 9.5L x 15” and 15 x 6 x 6 bolt 2
AR=As Required
