OPTIONAL: ULTIMATE V-RAKE RMT PARTS LIST
RUBBER MOUNTED TOOTH (RMT) KICKER WHEEL PARTS
Ref. Part No. Description Qty.
1 ULT4120 Mounting Clevis 1
2 ULT4130 Front Frame Assembly 1
3 ULT4110 Pivot Mount 1
ULT41502 Plate, Attaching 1
4 ULT4150RMT Rear Frame Assembly 1
5 ULT41501 Cylinder Mount, Rear Frame 1
ULT41502 Plate, Attaching 1
6 ULT4140 Vertical Post RMT 1
ULT41402 Plate, Attaching 1
7 ULT4160RMT Wheel Frame Assembly RMT 1
8 14344455 Axle, Kicker (Ultimate) 1
9 ULT4131 Hinge Pin, Front Frame 1
10 50C150HCS5Z Bolt, 1/2”-13 x 1-1/2” HHC G5 1
11 843102500 Cross, 1/2” Pipe, Female 1
12 75C200HCS5Z Bolt, 3/4”-10 x 2” HHC G5 6
13 PSW-2202-64BX Bushing, 2-1/2” x 2-1/4” x 3” Bronze 6
14 HD2508 Cylinder, 2-1/2” x 8” 1
15 1211509 Tee, 1/2” Female Steel 2
16 0107-8-8 Swivel Fitting, 1/2” 2
17 WR1027 Pin, 1” x 2-3/8” Headed 2
18 18R200PC00Z Cotter Key, 3/16” x 2” 2
19 100N150AMB0/10G Washer, 1” x 1-1/2” x 10 GA AR
100N150AMB0/14G Washer, 1” x 1-1/2” x 14 GA AR
20
21 ULT4132 Cylinder Link, Front Frame 1
22 ULT4136 Pin, Linkage, to Frame 1
23 62C600HCS5Z Bolt, 5/8”-11 x 6” HHC G5 4
24 62CNNE0Z/NE Nut, 5/8”-11 Lock 4
25 HD208 Cylinder, 2” x 8” 2
26 9405-8-8 Street Elbow, 1/2” 90 Deg. With Swivel 2
27 62C200HCS5Z Bolt, 5/8”-11 x 2” HHC G5 4
28
29 1503-8-8 Street Elbow, 1/2” 45 Deg. With Swivel 2
30 ULT41401 Hydraulic Tube, Vertical Post RMT 60” 1
31 WR4878RMT Holder, Compression Spring, Right, Green Chop 1
32 50CNFH5Z Nut, 1/2”-13 Fine Thread G5 2
33 50C125KSQT/CNP Set Screw, 1/2”-13 x 1-1/4” SQ-HD Cone Pt. 2
34 37C150HCS5Z Bolt, 3/8”-16 x 1-1/2” HHC 20
35 WR1507RMT Rod Guide Retainer Plate 5
36 WR78060 Bushing, Lift Rod, Green Chop 5
37
AR=As Required
