OPTIONAL: ULTIMATE V-RAKE RMT PARTS LIST
RUBBER MOUNTED TOOTH (RMT) KICKER WHEEL PARTS (continued)
Ref. Part No. Description Qty.
38 37CNNE0Z/NE Nut, 3/8” - 16 Lock 20
39 WR5205RMT Stabilizer, Lift Rod Roller 1
40 ULT4167 Linkage, Lift Rod Cylinder, RMT 1
41 107-100 Zerk, 1/4”-28 Str Lub 2
42 PM-BHF-3 Cap, Vent, 1/2” Cylinder Breather 1
43 ULT41621RMT Lift Rod 1
44 100CNFJ0Z Nut, 1”-8 Hex Jam 1
45 ULT4165 Lift Rod End Adjuster, RMT 1
46 50C400HCS5Z Bolt, 1/2”-13 x 4” HHC G5 1
47 ULT41392 Collar, Vertical Post 1
48 50CNNE0Z/NE Nut, 1/2”-13 Lock 1
49 62C500HCS5Z Bolt, 5/8”-11 x 5” HHC G5 8
50 62CNNE0Z/NE Nut, 5/8”-11 Lock 8
51 WR6053 Brake Disc with Bolt & Nut, Axle Wheel 8” 1
52 50CNFJ0Z Nut, 1/2”-13 Hex Jam 1
53 50C125KSQT/CNP Set Screw, 1/2”-13 x 1-1/4” SQ-HD Cone Pt 1
54 WR1030 Dampener, Wheel Lock with Poly Assembly 1
(See Page 41 for Parts Breakdown)
55 12420297 Spindle and Plate, 2” x 7”, 888 6 bolt 1
56 75C300HCS5Z Bolt, 3/4”-10 x 3” HHC G5 2
57 75NLOC0Z Washer, 3/4” Lock 2
58 75CNFH5Z Nut, 3/4”-10 Hex 2
59 195/50R15 Tire, Low Prole 195/50R15 1
60 0411141 Rim, 15 x 6 x 6 Bolt 1
61 207167 Hub Assembly, 888 6 Bolt 1
62 111-100 Zerk, 1/4”-28 90 Deg 1
63 RM-2247 Clamp (half) 1/4” x 1” x 3” 2
64 37CNNE0Z/NE Nut, 3/8”-16 Lock 2
65 844905060-BX Hydraulic Hose, 1/2” x 60” 2-wire 1
66 844905048-BX Hydraulic Hose, 1/2” x 48” 2-wire 4
67 844905036-BX Hydraulic Hose, 1/2” x 36” 2-wire 1
