Figure 8.
PR
CONDUIT LAYOUT FOR STANDARD FLUSHING, FRONTAL PRESSURE REGULATORS.
Flush
IN
OUT
PR
PR
PR
Pressure regulator
Figure 9.
Pressure regulator in the middle of the line :
maximum 2 lines can be flushed simultaneously.
Follow the same procedure as fig . First open
both end ball valves!
CONDUIT LAYOUT FOR STANDARD FLUSHING, CENTRAL PRESSURE REGULATORS.
Flush
IN
OUT
Pressure regulator
OUT
PR
PR
PR
PR
