SPARKcup- USER’S GUIDE INSTRUCTIONS FOR THE USER - EUG
ROXELL - 025 - 2416
19
HAND WINCH
TROUBLE SHOOTING GUIDE
Not respecting above-mentioned instructions can cause physical
injury or material damage.
Use p ersonal protective equipment.
DANGER
ACTIONS IN GREY BACKGROUND MUST BE DONE BY A TECHNICALLY TRAINED PERSON.
SEE TO IT THAT YOU FIRST REMOVE EACH ELEMENT WHICH CAN OBSTRUCT
A SAFE OPERATION OF THE SYSTEM!
CAUTION
IMPORTANT
PROBLEM
CAUSE CORRECTIVE ACTION
1. Brake doesn't work.
a. Screw thread on the drive shaft or the
handle is damaged.
- Replace the hand winch.
b. Screw thread on the drive shaft or the
handle is dirty.
- Clean the hand winch dry.
-Whennot ok, please ask a technically
trained person.
c. Brake disks are dirty. - Clean the hand winch dry.
-Whennot ok, please ask a technically
trained person.
d. Handle has been screwed up against
the locknut when turning down.
- Release the handle form t he locknut.
2. Winching up does-
n't work.
a. Load is too heavy. - Limit the load till max. 300 kg.
b. Cable to load is blocked somewhere. - Release the cable.
c. Drum weldment or drive shaft of the
hand winch is blocked because of dirt
or rust.
- Clean the hand winch and grease where
necessary.
3. Puttingdownthe
load doesn't work.
a. Safety lock is switched on. - Take the handle and unlock the safety
lock.
b. Cable to load is blocked somewhere. - Release the cable.
c. Drum weldment or drive shaft of the
hand winch is blocked because of dirt
or rust.
- Clean the hand winch and grease where
necessary.
MAINTENANCE INSTRUCTIONS
Use personal protective equipment.
DANGER
- Remove all dirt and dust after each batch or at least every 6 months.
- See to it that the handle turns fluently on the screw thread of the main shaft.
- Don't use water to clean the hand winch.
- Use grease to grease moving parts.
