RTI VSW-51 User Manual

Compact Scaler Switcher Set
5
customized EDID data.
 RS232: Serial port, 3-pin phoenix connector, connect with a control device (such
as PC) to control the Scaler Switcher or other devices connected with HDBaseT
Receiver.
 TCP/IP: Ethernet port, connect with PC to control the Scaler Switcher via GUI.
⑤ AUDIO OUTPUT
 Audio output port, the audio comes from the input audio corresponding to the
selected video source and is mixed with MIC audio.
⑥ DC 24V
 Power port, connect with DC 24V power adapter.
Note: Pictures shown in this manual are for reference only, different model and
specifications are subject to real product.
