RTI VSW-51 User Manual

Compact Scaler Switcher Set
16
4.3.3 RS232 Communication Commands
Communication protocol: RS232 Communication Protocol
Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none
Command
Function
Feedback Example
System Commands
#MOD?!
Report system model.
@MOD:VSW-51!
#IPA?!
Report IP address of device.
@IPA:192.168.0.100!
#RST!
Factory reset.
@RST:OK!
#POW?!
Report power status and Auto Off time.
@POW:ON!
@OUT:AUTO OFF 00!
@OUT:AUTO OFF 01!
@OUT:AUTO OFF 02!
@OUT:AUTO OFF 05!
@OUT:AUTO OFF 10!
#POW:ON!
Power on the system.
@POW:ON!
#POW:OFF!
Power off the system.
@POW:OFF!
#FPL?!
Report front panel lock status.
@FPL:LOCKED!
@FPL:UNLOCKED!
#FPL:LOCK!
Lock front panel button.
@FPL:LOCKED!
#FPL:UNLOCK!
Unlock front panel button (Default).
@FPL:UNLOCKED!
#FWV?!
Report firmware version.
@FWV:1.2.3!
#HWV?!
Report hardware version.
@HWV:4.5.6!
#FBK:OFF!
Disable feedback message.
@FBK:OFF!
#FBK:ON!
Enable feedback message (Default).
@FBK: ON!
#RPT:STATUS?!
Display status including MIC, Source
audio, Resolution, Manual/
Auto-switching modes, VGA audio mute
on/off, DP audio status.
@VOL:SRC 30!
@VOL:MIC 20!
@RAV:VIDEO 03 TO
OUT 01!
@RAV:AUDIO 03 TO
OUT 01!
