5. Specification
Video
Video input
1 HDMI/MHL; 2 HDMI; 1 DP; 1 VGA
Video Input Connector
3 female HDMI; 1 DisplayPort; 1 female VGA (15-pin)
Input Video Signal
HDMI, DP, YPbPr, C-video, VGA
Video Output
1 HDMI; 1 HDBaseT
Video Output Connector
1 female HDMI; 1 RJ45
Output Video Signal
HDMI; HDBaseT
Output Resolution
1920x1200, 1920x1080, 1600x1200, 1600x900,
1360x768, 1280x800, 1280x720, 1024x768.
Standards
Compliant with HDMI 1.4 & HDCP2.2
Audio
Audio Input
1 stereo audio input for DP;
1 stereo audio input for VGA;
1 Microphone audio
Audio Input Connector
2 3.5mm Stereo jacks; 1 3-Pin phoenix connector
Audio Input Impedance
>10kΩ
Audio Output
1 Dual-Mono analog audio
Audio Output Connector
1 5-Pin phoenix connector
Audio Output Impedance
70Ω
Frequency Response
20Hz~20K Hz
Stereo Channel
Separation
>80dB @1KHz
Control Part
Control port
1 IR IN; 1 IR OUT; 1 IR EYE; 1 RS232; 1 TCP/IP
Control Connector
3 3.5mm mini jack; 1 3-Pin phoenix connectors; 1 RJ45
General
Transmission Distance
1080P≤70m(Cat6)
Temperature
0 ~ +50℃
Humidity
10% ~ 90%
Power Supply
DC24V 2.71A
Power Consumption
27W
Dimension (W*H*D)
220mm x 44mm x 172.5mm
Weight
800g
