Command
Function
Feedback Example
!
#VOL:VGAUNMU
TE!
Unmute VGA Audio.
@VOL:VGA UNMUTE!
#VOL:VGAMUTE
?!
Inquiry Mute VGA Audio.
@VOL:VGA MUTE!
@VOL:VGA UNMUTE!
#VOL:DPAMUTE!
Mute DP Audio.
@VOL:DPA MUTE!
#VOL:DPAUNMU
TE!
Unmute DP Audio.
@VOL:DPA UNMUTE!
#VOL:DPAMUTE
?!
Inquiry Mute DP Audio.
@VOL:DPA UNMUTE!
@VOL:DPA UNMUTE!
#CFG:DPAEMB!
Select embedded audio as audio input
for DP video signal.
@CFG:DPA EMB!
#CFG:IDPAOEXT
!
Select external audio as audio input for
DP video signal.
@CFG:DPA EXT!
#CFG:DPA?!
Inquiry DP audio status.
@CFG:DPA EMB!
@CFG:DPA EXT!
Output Resolution Selection
#CFG:OUT01RE
SHD!
Set the output resolution to 1360X768
HD.
@CFG:OUT 01
RESHD!
#CFG:OUT01RE
SXGA!
Set the output resolution to 1024X768
XGA.
@CFG:OUT 01
RESXGA!
#CFG:OUT01RE
S720P!
Set the output resolution to 1280X720
720P.
@CFG:OUT 01
RES720P!
#CFG:OUT01RE
SWXGA!
Set the output resolution to 1280X800
WXGA.
@CFG:OUT 01
RESWXGA!
#CFG:OUT01RE
S1080P!
Set the output resolution to 1920X1080
1080P.
@CFG:OUT 01
RES1080P!
#CFG:OUT01RE
SWUXGA!
Set the output resolution to1920X1200
WUXGA.
@CFG:OUT 01
RESWUXGA!
#CFG:OUT01RE
SUXGA!
Set the output resolution to1600X1200
UXGA.
@CFG:OUT 01
RESUXGA!
#CFG:OUT01RE
SHD+!
Set the output resolution to 1600X900.
@CFG:OUT 01
RESHD+!
