Ruckus Wireless ZoneFlex 7762 - Mounting Kit Contents

4
Unpacking the ZoneFlex Access Point
Package Contents
Figure 3. Electrical shunt for resetting the Access Point to factory default settings
Mounting Kit Contents
■ Dynamic bracket
■ Static bracket
■ Steel clamp (2 pieces)
■ Machine screws (8 pieces)
■ Hex bolts (4 pieces)
■ Flat washers (4 pieces)
■ Split lock washers (4 pieces)
■ Wall anchors (4 pieces)
Figure 4. Mounting kit contents
Dynamic bracket Static bracket Steel clamp (2 pieces) Machine screw (8 pieces)
Hex bolt (4 pieces) Flat washer (4
pieces)
Split lock washer (4
pieces)
Wall anchor with metal
cone and hex nut
(4 pieces)
