RuggedCom RuggedSwitch RSG2100 User Manual

Technical Specifications
3.5.2 Gigabit Ethernet (1000 Mbps) Optical Specifications
For maximum flexibility RuggedCom Inc. offers a number of different transceiver choices
for Gigabit fiber optical communications. The table below details fiber optic specifications
based on the 2-port modules or pluggable transceivers selected at time of ordering.
Optics
Order
Code
Speed
Standard
Mode /
Connector
Tx
(nm)
Cable Type
(um)
Tx
min
(dBm)
Tx
max
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Typical
Distance
(km)
Power
Budget
(dB)
12-11-0036 1000SX MM/LC 850 62.5/125 -9.5 -4 -20 0 0.4 10.5
MM/LC 850 50/125 -9.5 -4 -20 0 0.7 10.5
12-11-0027 1000LX SM/LC 1310 9/125 -9.5 -3 -21 -3 10 11.5
12-11-0028 1000LX SM/LC 1310 9/125 -5 0 -24 -3 25 19
12-11-0025 1000LX SM/SC 1310 9/125 -10 -3 -20 -3 10 10
12-11-0026 1000LX SM/SC 1310 9/125 -5 0 -20 -3 25 15
25-10-0111 1000SX MM/LC 850 62.5/125 -9 -2.5 -20 0 0.3 11
850 50/125 -9 -2.5 -20 0 0.55 11
25-10-0100 1000LX SM/LC 1310 9/125 -9.5 -3 -21 -3 10 11.5
25-10-0101 1000LX SM/LC 1310 9/125 -3 2 -23 -3 25 20
25-10-
0108
5
1000LX SM/LC 1550 9/125 -6 0 -23 -3 40 17
25-10-
0109
4
1000LX SM/LC 1550 9/125 0 5 -23 -3 70 23
25-10-0202 1000BX SM/SC 1310
SIMPLEX
9/125
-9 -3 -22 -3 10 13
25-10-
0203
4
1000BX SM/SC 1490
SIMPLEX
9/125
-9 -3 -22 -3 10 13
25-10-0102 1000LX SM/SC 1310 9/125 -9.5 -3 -21 -3 10 11.5
25-10-0103 1000LX SM/SC 1310 9/125 -3 2 -23 -3 40 20
25-10-
0113
4
1000LX SM/SC 1550 9/125 0 5 -23 -3 70 23
Table 8: Gigabit Ethernet optical specifications
RuggedSwitch
®
RSG2100 31 RuggedCom
®

RuggedCom RuggedSwitch RSG2100 Specifications

General

Operating Temperature	-40°C to +85°C (-40°F to +185°F)
Power Supply	88-300 VAC/VDC
Mounting	DIN rail or panel mount
Management	Web-based, CLI, SNMP
Protection	Surge protection
Dimensions	135 x 196 x 119 mm
Standards Compliance	IEC 61850-3, IEEE 1613, EN 50121-4
Weight	0.8 kg (1.76 lb)
