RuggedCom RuggedSwitch RSG2100P User Manual

6.5.1 Fast Ethernet (10/100 Mbps) Optical Specifications
The dual-port fast Ethernet optical specifications for RSG2100P ports 1-8 and 13-20 are shown
below organized by module order code. Module order codes are contained within each product’s
factory data when assembled and configured at the factory. Consult the RuggedCom ROS to
determine the optical assemblies installed in a particular product.
Optics
Order
Code
Speed
Standard
Mode /
Connector
Tx
(nm)
Cable
Type
(um)
Tx
min
(dBm)
Tx
max
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Typical
Distance
(km)
Power
Budget
(dB)
12-11-0011 10FL MM/ST 820 62.5/125 -16 -9 -34 -11.2 2 18
50/125 -19.8 -12.8 -34 -11.2 2 14.2
12-11-0012 10FL SM/ST 1310 9/125 -27 -14 -35 -3 5 8
12-11-0007 100FX MM/ST 1300 62.5/125 -19 -14 -33.9 -14 2 14.9
50/125 -22.5 -14 -33.9 -14 2 11.4
12-11-0009 100FX MM/SC 1300 50/125 -22.5 -14 -33.9 -14 2 11.4
62.5/125 -19 -14 -33.9 -14 2 14.9
12-11-0008 100FX MM/MTRJ 1300 50/125 -22.5 -14 -33.5 -14 2 11
62.5/125 -19 -14 -33.5 -14 2 14.5
12-11-0046 100FX MM/LC 1310 62.5/125 -19 -14 -32 -14 2 13
12-11-0006 100FX SM/ST 1310 9/125 -15 -7 -34 -3 20 19
12-11-0005 100FX SM/SC 1300 9/125 -15 -8 -31 -7 20 16
12-11-0004 100FX SM/LC 1300 9/125 -15 -8 -38 -3 20 23
12-11-0031 100FX SM/SC 1310 9/125 -5 0 -34 -3 50 29
12-11-0032 100FX SM/LC 1310 9/125 -5 0 -35 -3 50 30
12-11-0033 100FX SM/SC 1310 9/125 5 0 -37 0 90 42
12-11-0034 100FX SM/LC 1310 9/125 0 5 -37 0 90 37
Table 13: Fast Ethernet optical specifications
