6.8 Mechanical Specifications
Parameter Value Comments
Dimensions 18.29 x 10.17 x 1.74 inches
(464,57) x (258,32) x (44,20) mm
(Length x Width x Height)
with mounting brackets
installed
Weight 10 lb (4.5 Kg)
Enclosure 18awg galvanized steel
Table 17: Mechanical Specifications
Figure 28: Mechanical Specifications
35
© 2008 RuggedCom Inc. All rights reserved Rev105
