RuggedCom RuggedSwitch RSG2100P - Table 2: LED Display - Port LED Behavior Definition

The port-based LEDs can be cycled between three display modes: Status, Duplex, and Speed.
Pushing the mode button causes the display mode to be cycled. Table 2 defines the possible port
LED colours and the corresponding description.
Mode Colour Description
Green (Solid) Link
Green (Blinking) Activity
Status
Off No link
Green (Solid) Full-Duplex operation
Orange (Solid) Half-Duplex operation
Duplex
Off No link
Green (Blinking) 1000Mb/s
Green (Solid) 100Mb/s
Orange (Solid) 10Mb/s
Speed
Off No link
Table 2: LED Display - Port LED behavior definition
9
