Ruijie Reyee RG-EG300GH-E Series User Manual

Hardware Installation and Reference Guide Product Overview
9
ports and one WAN port. One LAN port can be switched to the WAN port.
Four ports are IEEE 802.3af/at-compliant.
Power Supply
AC input:
Rated Voltage Range: 100 V AC to 240 V AC
Maximum Voltage Range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated current: 1.5 A
Power cord requirements: 10 A power cord
Adapter DC Connector
Specifications
Inner diameter: 2.1 mm (0.08 in.)
Outer diameter: 5.5 mm (0.22 in.)
Depth: 10.0 mm (0.39 in.) ± 0.3 mm (0.02 in.)
Polarity symbol: the center (tip) of the output plug is positive (+) and the barrel
(ring) of the output is negative (-).
Ground Leakage
Current
≤ 3.5 mA
EEE Function
Supported
PoE Function
IEEE 802.3af/at-compliant PoE output power ≤ 60 W
Power Consumption
< 80 W
Operating Temperature
0ºC to 40ºC (32°F to 104°F)
Storage Temperature
-40ºC to 70ºC (-40°F to 158°F)
Operating Humidity
10% to 90% RH (non-condensing)
Storage Humidity
5% to 95% RH (non-condensing)
Fan Module
Fanless
Temperature Alarming
Not Supported
EMC Certification
GB9254 CLASS A
EN 55032:2015+AC:2016
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 55035:2017
ETSI EN 300 386 V2.1.1 (2016-07)
Safety Regulation
Compliance
GB4943-2011
EN 62368-1
Dimensions (W x D x H)
202 mm x 109.5 mm x 28 mm (7.95 in. x 4.31 in. x 1.10 in., with the panel)
