Page #18 background imageLoading...
Page #18 background image
Hardware Installation and Reference Guide Product Overview
11
EN 55032:2015+AC:2016
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 55035:2017
ETSI EN 300 386 V2.1.1 (2016-07)
Safety Regulation
Compliance
GB4943-2011
EN 62368-1
Dimensions (W x D x H)
440 mm x 201.5 mm x 43.6 mm (7.95 in. x 4.31 in. x 1.10 in., with the panel)
440 mm x 200 mm x 43.6 mm (7.95 in. x 4.25 in. x 1.10 in., without the panel)
Weight
2.35 kg (5.18 lbs)
1.4.3 RG-EG310GH-P-E
Table 1-13 Technical Specifications of an RG-EG310GH-P-E Router
Model
RG-EG310GH-P-E
CPU
Dual-core CPU with the clock speed of 1.35 GHz
Flash Memory
256 MB
SDRAM
DDRIII 512 MB
Fixed Service Ports
Ten 10/100/1000BASE-T Ethernet RJ45 with auto negotiation, including nine
LAN ports and one WAN ports. Three LAN ports can be switched to the WAN
ports
Eight ports are IEEE 802.3af/at-compliant.
Power Supply
AC input:
Rated voltage range: 100 V AC to 240 V AC
Maximum voltage range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated current: 2.5 A
Power cord requirements: 10 A power cord
Adapter DC
Connector
Specifications
Inner diameter: 2.1 mm (0.08 in.)
Outer diameter: 5.5 mm (0.22 in.)
Depth: 10.0 mm (0.39 in.) ± 0.5 mm (0.02 in.)
Polarity symbol: the center (tip) of the output plug is positive (+) and the barrel
(ring) of the output is negative (-).
Ground Leakage
Current
3.5 mA
