Hardware Installation and Reference Guide Product Overview
3
1.3 Product Appearance
1.3.1 RG-EG305GH-P-E
Figure 1-1 RG-EG305GH-P-E Router Appearance
Figure 1-2 Front Panel of an RG-EG305GH-P-E Router
Table 1-5 Front Panel Specifications
Fast blinking green: The router is starting up.
Solid green: The router is functioning properly.
Slow blinking green: 1. The router is restoring factory default settings. 2.
The router is upgrading the software.
Press for less than 2 seconds to reboot the router.
Press for more than 5 seconds until the system LED flashes to restore the
router to factory default settings. (The device does not respond if you press
the Reset button for 2s to 5s).
10/100/1000BASE-T Ethernet RJ45 with auto negotiation, compliant with the
IEEE 802.3af (PoE) and 802.3at (PoE+) standards. Connect the LAN port to the
PC, the switch or the access point with an Ethernet cable.
