Ruijie Reyee RG-EG300GH-E Series User Manual

Hardware Installation and Reference Guide Product Overview
10
202 mm x 108 mm x 28 mm (7.95 in. x 4.25 in. x 1.10 in., without the panel)
Weight
0.45 kg (0.99 lbs)
Caution
Please use the power adapter and power cord delivered with the router by Ruijie Networks.
1.4.2 RG-EG310GH-E
Table 1-12 Technical Specifications of an RG-EG310GH-E Router
Model
RG-EG310GH-E
CPU
Dual-core CPU with the clock speed of 1.35 GHz
Flash Memory
256 MB
SDRAM
DDRIII 512 MB
Fixed Service Ports
Ten 10/100/1000BASE-T Ethernet RJ45 with auto negotiation, including nine LAN
ports and one WAN ports. Three LAN ports can be switched to the WAN ports.
Power Supply
AC input:
Rated voltage range: 100 V AC to 240 V AC
Maximum voltage range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated current: 0.6 A
Power cord requirements: 10 A power cord
Ground Leakage
Current
≤ 3.5 mA
EEE Function
Supported
PoE Function
Not Supported
Power Consumption
< 15 W
Operating Temperature
0ºC to 40ºC (32°F to 104°F)
Storage Temperature
-40ºC to 70ºC (-40°F to 158°F)
Operating Humidity
10% to 90% RH (non-condensing)
Storage Humidity
5% to 95% RH (non-condensing)
Fan Module
Fanless
Temperature Alarming
Not Supported
EMC Certification
GB9254 CLASS A

Ruijie Reyee RG-EG300GH-E Series Specifications

General

Brand	Ruijie
Model	Reyee RG-EG300GH-E Series
Category	Network Router
Language	English
