Web-based Configuration Guide Advanced Configuration
115
Table 8-1 Description of STP Global Configuration Parameters
Whether to enable the STP function. It takes effect globally. STP attributes
can be configured only after STP is enabled.
Bridge priority. The device compares the bridge priority first during root bridge
selection. A smaller value indicates a higher priority.
The maximum expiration time of BPDUs The packets expiring will be
discarded. If a non-root bridge fails to receive a BPDU from the root bridge
before the aging time expires, the root bridge or the link to the root bridge is
deemed as faulty
Network recovery time when redundant links occur on the network.
Interval for sending two adjacent BPDUs
The interval at which the port status changes, that is, the interval for the port
to change from Listening to Learning, or from Learning to Forwarding.
The versions of Spanning Tree Protocol. Currently the device supports STP
(Spanning Tree Protocol) and RSTP (Rapid Spanning Tree Protocol).
8.1.2 Applying STP to a Port
Choose Local Device > Advanced >STP > STP.
Configure the STP properties for a port Click Batch Edit to select ports and configure STP parameters, or click
Edit in the Action column in Port List to configure designated ports.
