Hardware Installation and Reference Guide Product Overview
21
(W x D x H)
Weight
3 kg (6.61 lbs.)
Appearance
The front panel of the RG-S5300-48GT4XS-E switch provides 48 10/100/1000Base-T Ethernet ports, four 10GE SFP+ ports, one
management port, one Console port and one USB port. The back panel has an AC power plug.
Figure 1-21 RG-S5300-48GT4XS-E Switch Appearance
Front Panel
Figure 1-22 Front Panel of RG-S5300-48GT4XS-E
1. System Status LED
2. Management Port LED
3. USB Port
4. Console Port
5. Management Port
6. 10/100/1000Base-T Ethernet Port
7. 10GE SFP+ Port
8. Port LED
Back Panel
Figure 1-23 Back Panel of RG-S5300-48GT4XS-E
