Ruijie RG-S5300-E Series - 1.10 RG-S5310-48 GT4 XS-P-E

Hardware Installation and Reference Guide Product Overview
34
Solid Green
System is operating normally.
Solid Yellow
The temperature at the air intake and exhaust vents
exceeds the threshold.
Solid Red
1. The temperature at the air intake and exhaust vents
exceeds the threshold greatly.
2. The system is not functioning properly.
Management Port LED
MGMT
Off
No link is detected for this port.
Solid Green
The port has made a successful 1000 Mbps link.
Blinking Green
The port is sending and receiving traffic at 1000 Mbps.
Solid Yellow
The port has made a successful 10/100 Mbps link.
Blinking Yellow
The port is sending and receiving traffic at 10/100 Mbps.
LED Mode Indicator
LED Mode
Solid Green
Switching status
Solid Yellow
PoE status
10GE SFP+ Port LED
25F to 28F
Off
No link is detected for this port.
Solid Green
The port has made a successful 1/10 Gbps link.
Blinking Green
The port is sending and receiving traffic at 1/10 Gbps.
10/100/1000Base-T
Ethernet Port LED
1F to 24F
Off
No link is detected for this port.
Solid Green
The port has made a successful 10/100/1000 Mbps link.
Blinking Green
The port is sending and receiving traffic at 10/100/1000
Mbps.
PoE Status LED
1F to 24F
Off
PoE is disabled.
Solid Green
PoE is enabled.
Blinking Green
(3 Hz)
PoE overload occurs.
LED Mode Button
The LED Mode button is used to switch the LED mode. The green LED Mode indicator indicates the switching status. Press the LED
Mode button, and the LED Mode indicator will turn yellow, indicating the PoE status. Press the LED Mode button again, the indicator
switches to indicating the switching status.
If you want to switch the LED mode, press the button for over two seconds.
1.10 RG-S5310-48GT4XS-P-E
Specifications
Model
RG-S5310-48GT4XS-P-E
CPU
Dual-core CPU with the clock speed of 1.2 GHz
BOOTROM
16 MB
Flash Memory
2 GB
SDRAM
1 GB
SFP Module Type
 SFP+ Port:
 SFP Modules and SFP BIDI Modules
