Item
Specification
Power Supply Model
RG-PA150IB-F
Switch Model
RG-S5310-48SFP4XS-E
Rated Input Voltage Range
AC Input: 100 V AC to 240 V AC, 50 Hz/60 Hz
HVDC Input: 240 V DC
Maximum Input Voltage
Range
AC Input: 90 V AC to 264 V AC, 47 Hz/63 Hz
HVDC Input: 192 V DC to 288 V DC
Maximum Input Current
3 A
Output Voltage
12 V
Maximum Output Current
12.5 A
Maximum Output Power
150 W
Ground Leakage Current
≤ 3.5 mA
Dimensions (W x D x H)
196 mm x 50.5 mm x 40 mm (7.72 in. x 1.99 in. x 1.57 in.)
Weight
0.55 kg (1.21 lbs.)
Operating Temperature
-10°C to 55°C (14°F to 131°F)
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Relative Operating
Humidity
5% to 95% RH (non-condensing)
Relative Storage Humidity
5% to 95% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above the sea level
Features
Features
Benefit
Conformal Coating
Moisture-proof, salt spray-proof, mold-proof, insulation-proof and leak-proof.
Protection
Undervoltage protection, output overcurrent protection, output overvoltage protection and output
short circuit protection.
I2C Communication
The switch can communicate with the power supply module through I2C.
Power Redundancy
System supports 1+1 power redundancy. Dual power supply modules are connected in parallel for
current sharing.
Hot Swapping
In the power redundancy mode, the power supply module can be replaced when the system is
powered on.
Alarming
When a power fault occurs, the output status LED turns off.
LED
Function
Color
Status
Output Status LED
Off
The power supply module is not outputing power properly.
Solid Green
The power supply module is outputing power normally.
1.13.3 RG-PD150IB-F Module
The RG-S5310-24GT4XS-E, RG-S5310-48GT4XS-E, RG-S5310-24SFP4XS-E and RG-S5310-48SFP4XS-E switches support the RG-PD150IB-
F power module. The RG-PD150IB-F is a DC module (DC input and DC output) providing an output voltage of 12 V and an output power
of up to 150 W.
