Hardware Installation and Reference Guide Product Overview
46
Solid Yellow
The temperature at the air intake and exhaust vents
exceeds the threshold.
Solid Red
1. The temperature at the air intake and exhaust vents
exceeds the threshold greatly.
2. The system is not functioning properly.
Power Supply Status LED
PWR1/PWR2
Off
The power supply module is not seated.
Solid Green
The power supply module is seated and providing
power to the switch.
Solid Yellow
The model of the power supply module is not
supported or cannot be identified.
Solid Red
The redundant power supply module is not functioning
properly or not connected with the AC power cord.
Management Port LED
MGMT
Off
No link is detected for this port.
Solid Green
The port has made a successful 1000 Mbps link.
Blinking Green
The port is sending and receiving traffic at 1000 Mbps.
Solid Yellow
The port has made a successful 10/100 Mbps link.
Blinking Yellow
The port is sending and receiving traffic at 10/100
Mbps.
10GE SFP+ Port LED
49F to 52F
Off
No link is detected for this port.
Solid Green
The port has made a successful 1/10 Gbps link.
Blinking Green
The port is sending and receiving traffic at 1/10 Gbps.
GE SFP Port LED
1F to 48F
Off
No link is detected for this port.
Solid Green
The port has made a successful 100/1000 Mbps link.
Blinking Green
The port is sending and receiving traffic at 100/1000
Mbps.
1.13 Power Supply Module
1.13.1 RG-PA70IB Module
The RG-S5310-24GT4XS-E, RG-S5310-48GT4XS-E and RG-S5310-24SFP4XS-E switches support the RG-PA70IB swappable power module.
The RG-PA70IB is an AC module (AC/HVDC input and DC output) providing an output voltage of 12 V and an output power of up to 70
W.
The switch can be powered on by either one power supply module or dual power supply modules. If both power supply modules
are used, the switch works in the power redundancy mode.
At least one power supply module is required. If any slot is unoccupied, install a filler panel to enable proper airflow.
Specifications
Item
Specification
Power Supply Model
RG-PA70IB
Switch Model
RG-S5310-24GT4XS-E, RG-S5310-48GT4XS-E, RG-S5310-24SFP4XS-E
Rated Input Voltage Range
AC Input: 100 V AC to 240 V AC, 50 Hz/60 Hz
