Function
Application
Explanation
Disinfection
Connector
It is used for disinfecting
media (resin or others)
in resin tank when
softener in
regeneration.
Under the Brine & Slow Rinse status, it
can make a part of brine water
electrolyzed, producing hypochlorous
acid to sterilize and disinfect the media
(resin or others) in resin tank.
Leakage
Protection
Connector
The valve automatically
turns to closed
protection position
when there is water
leakage in the pipeline.
Need to use the manufacturer's induction
cotton.
Disinfection connector
If need to connect with disinfection device, the disinfection connector as the Figure 6
shows.
3.3. System Configuration and Flow Rate Curve
A. Product configuration with tank, resin volume, brine tank and injector in industrial
application
Tank Size
(mm)
Resin
Volume
(L)
Flow
Rate
(m
3
/h)
Brine Tank
Size
(mm)
Minimum Salt
Consumption
for
Regeneration
（Kg）
Injector Nozzle
/ Throat
Regene
-ration
Type
φ180×1130
16
0.5
Φ250×520
2.4
Cyan / Cyan
Up-flow
Pink/Coffee
Down-fl
ow
φ205×
1300
25
0.7
φ390×
810
4.0
Pink/Coffee
Up-flow
Yellow/Pink
Down-fl
ow
φ255×
40
1.2
φ390×
6.0
Pink/Coffee
Up-flow
