DESCRIPTION OF THE INSTRUMENT
Axio Lab.A1 Technical data Carl Zeiss
04/2013 430037-7144-001 25
Cat. No. Binocular tube Transmitted
light
430037-9000-000
430037-9010-000
430037-9030-000
Conoscopy
430037-9040-000
Reflected light
430037-9020-000
430037-9050-000
425520-9050-000 Binocular ergo tube 15°/23
(50/50), telescopic, height,
upright image
Medium Medium Medium
Spacer Spacer ---
M M M
425520-9090-000 Binocular tube
20°/23 Mat
(analog 9030 without
camera output)
Small Small Small
Spacer Spacer ---
--- --- ---
425520-9100-000 Binocular photo tube
20°/23 Pol (100/100)
Medium Medium Medium
Spacer Spacer ---
M M M
425511-0000-000 Binocular ergo tube 20°/23,
reverse image, 44 mm
height
Medium Medium Medium
Spacer Spacer ---
M M M
425512-0000-000 Binocular ergo tube 20°/23
(100/100),
44 mm height
Medium Medium Medium
Spacer Spacer ---
M M M
425514-0000-000 Binocular ergonomoic tube
20°/23 (100/100), upright
image,
44 mm height
Medium Medium Medium
Spacer Spacer ---
M M M
* Included in shipping contents
Explanation of table:
Dust cover Small: 415510-1901 Medium: 459306-0000-000
Intermediate plate for tubes
(423732-9040-000)
Intermediate plate: necessary --- unnecessary
Base plate
(430037-910-000)
M: Mandatory M: recommended ---- unnecessary
