DESCRIPTION OF THE INSTRUMENT
Axio Lab.A1 Technical data Carl Zeiss
04/2013 430037-7144-001 23
2.3.1 Viewing height and tube angle
Order No. Binocular tube Viewing
angle
Adjustment Viewing
height* in mm
425522-9000-000 Binocular tube 30°/20 30° - none - 434 / 470
425522-9010-000 Binocular photo tube 30°/20 (50:50) 30° - none - 434 / 470
425522-9020-000 Binocular ergo tube 8-38°/20 8-38° Angle 407 - 534
425522-9030-000 Binocular ergo photo tube 838°/20
(50:50)
8-38° Angle 407 - 534
425522-9040-000 Binocular ergonomic tube 8-38°/22 8-33° Angle
Height
412 - 603
425520-9000-000 Binocular tube 30°/23 30° - none - 449 / 485
425520-9010-000 Bin. photo tube 30°/23 (50:50) 30° - none - 449 / 485
425520-9020-000 Bin. photo tube 30°/23 (100:100) Bio 30° - none - 449 / 485
425520-9030-000 Binocular photo tube 20°/23 (100:100) 20° - none - 442 / 481
425520-9040-000 Bin. ergo tube (100/100), angle-
adjustable, upright image
5-30° Angle 395 - 537
425520-9050-000 Bin. ergo tube 15°/23 (50/50),
telescopic, height, upright image
15° Height
telescopic
410 - 509
425520-9090-000 Binocular tube 20°/23 20° 442 / 481
425520-9100-000 Bin. photo tube 20°/23 Pol (100:100) 20° 442 / 481
425511-0000-000 Binocular ergo tube 20°/23,
44 mm height
20° Height 457 - 574
425512-0000-000 Bin. ergo tube 20°/23 (100/100), reverse
image, 44 mm height
20° Height 457 - 574
425514-0000-000 Bin. ergo tube 20°/23 (100/100),
upright image, 44 mm height
20° Height 457 - 574
*
Viewing heights:
Tubes with fixed viewing angle without ergo function:
Binocular part lower/upper e.g. 442 / 481 o 442 to 481 mm
Angle- and vertically adjustable ergo tubes:
Binocular part lower/upper e.g. 457 / 574 o 457 to 574 mm
All specifications are for an interpupillary distance of 65 mm.
