14.8. Seam cycle timing diagram (Annex G)
C.P.= Pressure switch
P1= Press. 1 Squeeze (o entire Seam cycle)
P2= Press. 2 Pre squeeze
P3= Press. 3 Pre weld
P4= Press. 4 weld
P5= Press. 5 Forge
PU= Spot
PA= Pause
