SafeLine
MX3+
MX3+ v1.06 EN
© 2018 SafeLine and all the SafeLine products and accessories are copyrighted by law.
TECHNICAL DATA
Supply voltage: 10 to 30 VDC
Supply current: In standby: 50 mA at 12 VDC
When connected: 160 mA at 12 VDC
Alarm button input: 10 to 30 VDC, 5 mA optically isolated
Input: 10 to 30 VDC, 5 mA optically isolated
Output: 2x 12 to 24 VDC, max 200 mA (transistor negative)
Weight: Flush mounted (no button): 535 g
Flush mounted with button: 555 g
Surface mounted (no button): 510 g
Surface mounted with button: 575 g
Car Operating Panel: 380 g
Size (H x W x D): Flush mounted (no button): 155 x 90 x 14 mm
Flush mounted with button: 155 x 90 x 28 mm
Surface mounted (no button): 136 x 78 x 16 mm
Surface mounted with button: 155 x 90 x 31 mm
Car Operating Panel: 88 x 53 x 14 mm
IP class: IP 43
Bluetooth: Bluetooth 4.0
BLE 2,4 GHz
