Safeline MX3+ - Page 7

7
102,2
43,6
77,6
16,2
136,2
2 x Ø4,5
R5
90
155
117
54
30,7
2 x Ø4
R5
MX3+ v1.06 EN
© 2018 SafeLine and all the SafeLine products and accessories are copyrighted by law.
Installation
Surface mount SafeLine MX3+ with
pictograms
Article number: *SLMX3-SM-PIC
Surface mount SafeLine MX3+ with
pictograms and emergency alarm button
Article number: *SLMX3-SM-PICB
MEASUREMENTS AND COMPONENTS LIST
