102 VG5 Installation & Quick-Start Manual
Protection
Function L4 Reference Detection
L4-01
Frequency
Detection Level
(Spd Agree Level)
0.0~
400.0
0.1Hz 0.0 x B B B B
L4-02
Frequency
Detection Width
(Spd Agree Width)
0.0~
20.0
0.1Hz 2.0 x B B B B
L4-03
Frequency
Detection Level ±
(Spd Agree Lvl ±)
–400.0 ~
+400.0
0.1Hz 0.0 x A A A A
L4-04
Frequency
Detection Width ±
(Spd Agree Wdth ±)
0.0~
20.0
0.1Hz 2.0 x A A A A
L4-05
Frequency Loss
Detection Selection
(Ref Loss Sel)
0, 1 1 0
0: (Stop)
1: (Run@ 80% PrevRef)
x A A A A
Function L5 Fault Restart
L5-01
Number of Auto
Restart Attempts
(Num of Restarts)
0~10 1 0 x B B B B
L5-02
Auto Restart
Operation Selection
(Restart Sel)
0, 1 1 0
0: (No Flt Relay)
1: (Flt Relay Active)
x B B B B
Function L6 Torque Detection
L6-01
Overtorque
Detection
Selection 1
(Torq Det 1 Sel)
0~4 1 0
0: (Disabled)
1: (@SpdAgree - Alm)
Detected during speed
agree only. Operation con-
tinues after detection and
OL3 flashes on display.
2: (At RUN - Alarm)
Overtorque detection during
running. Operation contin-
ues after detection and OL3
flashes on the display.
3: (@SpdAgree - Flt)
Detected during the speed
agree only. Inverter trips on
OL3, output is shut OFF.
4: (At RUN - Fault)
Detected during running,
and the inverter trips on
OL3. Output is shut OFF.
x B B B B
Function
Parameter
No.
Name
(Digital Operator
Display)
Setting
Range
Setting
Unit
Factory
Setting
Remarks
(Digital Operator Display)
Change
during
Operation
o: Enabled
x: Disabled
Parameter Access Level
User
Setting
V/f
V/f
w/
PG
Open
Loop
Vector
Flux
Vector
Appendix
VG5 Parameters
