76 VG5 Installation & Quick-Start Manual
A.3 VG5 Parameters
Function
Parameter
No.
Name
(Digital Operator
Display)
Setting
Range
Setting
Unit
Factory
Setting
Remarks
(Digital Operator Display)
Change
during
Operation
o: Enabled
x: Disabled
Parameter Access Level
User
Setting
V/f
V/f
w/
PG
Open
Loop
Vector
Flux
Vector
Initialize
Initialization
A1-00
Language
Selection
(Select Language)
0.1 1
1
(Note1)
0: English
1: Japanese
2: Deutsch
<1110>
3: Francais <1110>
4: Italiano <1110>
5: Espanol <1110>
6: Portugues <1110>
o Q Q Q Q
A1-01
Access Level
(Access Level)
0~4 1 2
0: Operation Only
1: User Level (Note 5)
2: Quick-Start [Q]
3: Basic Level [B]
4: Advanced Level [A]
o Q Q Q Q
A1-02
Control Method
Selection
(Control method)
0~3 1
0
(Note1)
0: V/F Control
1: V/F w/PG Fdbk
2: Open Loop Vector
3: Flux Vector
x Q Q Q Q
A1-03
Initialize
(Init Parameters)
0
1110
2220
3330
N/A 0
0 : No Initialize
1110: User Initialize (Note 7)
2220: 2-Wire Initialize
3330: 3-Wire Initialize
x Q Q Q Q
A1-04
Password 1 *
(Enter Password)
0000~
9999
1 0000
Password protection for:
A1-01 Access Level
A1-02 Control Method
A1-03 Initialization
A2-01 to A2-32 User Parame-
ters (If selected)
x Q Q Q Q
User Parameters
A2-01
~
A2-32
User Setting
Parameters
(Function A2)
— — —
User Parameter 1 to
User Parameter 32
x A A A A
Note 1 Not initialized. (Domestic standard specifications: A1-01 = 1, A1-02 = 2)
Note 2 Setting range is only 0 and 1 when the control method is set to flux vector control (A1-02 = 3)
Note 5 Selection “1: User Level” is only available after selecting setting 4: Advanced Level and then entering a user parameter in A2-01.
Note 7 Setting 1110: User Initialize is only available after setting Parameter No. O2-03 to 1.
Appendix
VG5 Parameters
