70 VG5 Installation & Quick-Start Manual
A.1 VG5 Parameter Tree
MENU
Group Function
Parameter No.
Quick-start Basic Advanced
U1-01 Frequency Referance 01
U1-02 Output Frequency 02
U1-03 Output Current 03
U1-06* Output Voltage* 06*
U2 Fault trace 01-14
U3 Fault history 01-08
U1 Monitor 01-14 15-19 20-35
A1 Initialize 00-04
A2 User parameters 01-32
B1 Sequence 01-03 04 05-08
B2 DC braking 01-04
B3 Speed search 01-03
B4 Delay timers 01, 02
B5 PID control 01-11
B6 Reference hold 01-04
B7 Droop control 01, 02
B8 Energy savings 01, 02
B9 Zero servo 01, 02
C1 Accel/decel 01, 02 03, 04, 09 05-08, 10, 11
C2 S-curve accel/decel 01-04
C3 Motor slip compensation 01 02-07
C4 Torque compensation 01 02-05
C5 ASR tuning 01-04 05-08
C6 Carrier frequency 01 02, 03
C7 Hunting prevention 01, 02
C8 Factory Tuning 08, 09, 30, 31
D1 Preset reference 01-04, 09 05-08
D2 Reference limit 01, 02
D3 Jump frequencies 01-04
D4 Sequence 01, 02
D5 Torque control 01-06
E1 V/f pattern 1 01-10 11-13
E2 Motor set-up 1 01-04 05-10
E3 Control method 2 01
E4 V/f pattern 2 01-07
E5 Motor set-up 2 01-03, 05, 06
F1 PG option set-up 01 02-07 08-13
F2 AI-14 set-up 01
F3 DI-08, 16 set-up 01
F4 AO-08, 12 set-up 01-04 05, 06
F5 DO-02 set-up 01,02
F6 DO-08 set-up 01
F7 PO-36F set-up 01
F8 SI-F/G set-up 01
F9 CP-916 set-up 01-06
H1 Digital inputs 01-06
H2 Digital outputs 01-03
H3 Analog inputs 01-07 08-12
H4 Analog outputs 01-07
H5 Serial communication set-up 01-05
L1 Motor overload 01, 02
L2 Power loss ridethrough 01-03 04-06
L3 Stall prevention 01, 02, 04-06 03
L4 Reference detection 01, 02 03-05
L5 Fault restart 01, 02
L6 Torque detection 01-03 04-06
L7 Torque limit 01-04
L8 Hardware protection 01 02, 03, 05, 07, 10
O1 Monitor select 01-04 05
O2 Key select 01-04 05-09
ReferenceD
MotorE
OptionF
ApplicationB
InitializeA
Programming
Modified constants
Auto-tuning
Operation
TuningC
TerminalH
ProtectionL
OperatorO
* User Selectable
Appendix
VG5 Parameter Tree
