VG5 Installation & Quick-Start Manual 9
1.3 VG5 SPECIFICATIONS
230V
460V
* HP ratings based on NEMA 4-pole motor data. However, when sizing a drive to match a motor, use output current ratings.
#
For proper operation, the motor rated current must be less than or equal to the inverter rated current.
** kVA ratings are based on 200V, 400V, and 600V inputs respectively.
Inverter Model
CIMR-G5U
VG5
20P4 20P7 21P5 22P2 23P7 25P5 27P5 2011 2015 2018 2022 2030 2037 2045 2055 2075
Output Characteristics
Nominal Motor Output
(HP) *
0.5 1 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100
Capacity (kVA)** 1.2 2.3 3.0 4.2 6.7 9.5 13 19 24 30 37 50 61 70 85 110
Rated Output Current
(A)
#
3.2 6 8 11 17.5 25 33 49 64 80 96 130 160 183 224 300
Max. Voltage
3-Phase, 200/208/220/230V
(Proportional to input voltage)
Rated Output
Frequency
Up to 400 Hz available
Overload Capacity 150% Rated Current / 1 minute
Power Supply
Input Current (A) 3.9 7.2 9.6 13.2 21 30 40 59 77 88 106 143 176 202 247 330
Rated Voltage &
Frequency
3-Phase
200 to 230V, 50/60Hz
Voltage Fluctuation +10%, -15%
Frequency Fluctuation ±5%
CIMR-G5U 40P440P741P542P243P744P045P547P5401140154018402240304037404540554075 41104160418542204300
Output Characteristics
Nominal Motor Output
(HP) *
0.5 1 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100 125 150 200 250 350 500
Capacity (kVA)** 1.4 2.6 3.7 4.7 6.1 8.4 11 16 21 26 31 40 50 61 73 98 130 170 230 260 340 460
Rated Output Current
(A)
#
1.9 3.6 5.1 6.6 8.5 11.7 14.8 21 28.6 34 41 52 65 80 96 128 165 224 302 340 450 605
Max. Voltage
3-Phase, 380/400/415/440/460V
(Proportional to input voltage)
Rated Output
Frequency
Up to 400 Hz available
Overload Capacity 150% Rated Current / 1 minute
Power Supply
Input Current (A) 2.3 4.3 6.1 8 10.2 14 17.8 26 35 40 46 58 72 88 106 141 182 247 330 408 540 726
Rated Voltage &
Frequency
#
3-Phase
380 to 460V, 50/60Hz
Voltage Fluctuation +10%, -15%
Frequency Fluctuation ±5%
Chapter 1 - Receiving & Installation
Specifications
