46 VG5 Installation & Quick-Start Manual
Quick-Start Parameter Sequence
* Depress the Menu key on the digital operator to return to Main Menu: Operation.
Main Menu * Key Press Function
Parameter
No.
Operation
Frequency Reference U1-01
 Output Frequency U1-02
 Output Current U1-03
 Output Voltage U1-06

DATA/ENTER
U2 Fault Trace
U2-01 to U2-14
U2

DATA/ENTER
U3 Fault History
U3-01 to U3-08
U3

DATA/ENTER
U1 Monitor
U1-01 to U1-14
U1
Initialize
ESC
DATA/ENTER
Select Language A1-00
 Access Level A1-01
 Control Method A1-02
 Initialize Parameters A1-03
 Enter Password A1-04
Programming
ESC
DATA/ENTER
Reference Source B1-01
 Run Source B1-02
 Stopping Method B1-03
 Acceleration Time 1 C1-01
 Deceleration Time 1 C1-02
 Preset Frequency Reference 1 D1-01
 Preset Frequency Reference 2 D1-02
 Preset Frequency Reference 3 D1-03
 Preset Frequency Reference 4 D1-04
 Jog Frequency Reference D1-09
 Input Voltage E1-01
 Motor Selection E1-02
 V/f Pattern Selection E1-03
 Maximum Frequency E1-04
 Maximum Voltage E1-05
 Maximum Voltage Output Frequency E1-06
 Middle Output Frequency E1-07
 Middle Output Voltage E1-08
 Minimum Output Frequency E1-09
 Minimum Output Voltage E1-10
 Base Voltage E1-13
 Motor Rated Current E2-01
 Motor Rated Slip Frequency E2-02
 Motor No-Load Current E2-03
 Number of Motor Poles E2-04
Auto-Tuning
ESC
DATA/ENTER
Rated Voltage --
 Rated Current --
 Rated Frequency --
 Rated Speed --

Number of Poles --
 Select Motor 1 or 2 --
Modified Constants
ESC
DATA/ENTER
Chapter 3 - Quick-Start Programming
Quick-Start Parameter Sequence
