106 VG5 Installation & Quick-Start Manual
Operator
Function o2 Key Selection
O2-03
User Parameter Ini-
tialization Selection
(User Defaults)
0, 1, 2 1 0
0: (No Change)
manufacturer default values
used
1: (Set Defaults)
Sets user specified value as
default.
2: (Clear All)
Clears user defaults
x B B B B
O2-04
kVA Selection
(Inverter Model #)
0~FF 1 –*
* Not initialized. Sets the
inverter capacity according
to the model number.
x B B B B
O2-05
Frequency Refer-
ence Setting
Method Selection
(Operator M.O.P.)
0, 1 1 0
0: (Disabled)
1: (Enabled)
x A A A A
O2-06
Operation Selec-
tion When Digital
Operator is Discon-
nected
(Oper Detection)
0, 1 1 0*
0: (Disabled) Operation contin-
ues even if the digital opera-
tor is disconnected.
1: (Enabled) Inverter fault
when the digital operator is
disconnected.
* When 02-09=1, the value is 1.
x A A A A
O2-07
Elapsed Timer
Setting
(Elapsed Time Set)
0~
65535
1 hour — — x A A A A
O2-08
Elapsed Timer
Selection
(Elapsed Time Run)
0, 1 1 0
0: (Power - On Time)
1: (Running Time)
x A A A A
O2-09
Initialization Mode
Selection
(Init Mode Sel)
0~3 1 0
0: (Japanese spec)
1: (American spec)
2: (European spec)
3: (OMRON spec)
When 02-09 = 1 or 2, it is
added by
<1032>.
When 02-09 = 0 or 3, it is
added by
<1040>.
x A A A A
Function
Parameter
No.
Name
(Digital Operator
Display)
Setting
Range
Setting
Unit
Factory
Setting
Remarks
(Digital Operator Display)
Change
during
Operation
o: Enabled
x: Disabled
Parameter Access Level
User
Setting
V/f
V/f
w/
PG
Open
Loop
Vector
Flux
Vector
Appendix
VG5 Parameters
