VG5 Installation & Quick-Start Manual 109
CE CONFORMANCE - Electro-Magnetic Compatibility (EMC) Compliance
In order to conform to EMC standards, exclusive-use methods are required for line filter applica-
tion, cable shielding and inverter installation. An outline of the methods follows.
The line filter and the inverter must be mounted on the same metal plate. The filter should be
mounted as close to the inverter as practical. Keep cable as short as possible. The metal plate should
be securely grounded. The ground of the line filter and inverter must be bonded to the metal plate
with as much area as possible.
For line power input cable, screened cable is recommended at least within the panel. The screen of
the cable should be connected to a solid ground. For the motor cable, screened cable (max. 20m)
must be used and the screen of the motor cable is connected to ground at both ends by a short con-
nection, using as large an area as practical.
The following table and figures show the line filter list for EMC standards and the installation/wir-
ing of inverter and line filter.
Line Filter List for EMC Standards
Inverter
Model
CIMR-
VG5Uxxxx
Line Filter (Manufactured by Schaffner)
Model
Rated
Current
(A)
Mass
(kg)
Dimensions (mm)
W D H
40P4
FS4874-7/07 7 1.1 50 126 25540P7
41P5
42P2
FS4874-18/07 18 1.7 55 142 30543P7
44P0
45P5
FS4874-30/07 30 1.8 60 150 335
47P5
4011
FS4874-42/07 42 2.8 70 185 329
4015
4018 FS4874-55/07 55 3.1 80 185 329
4022
FS4874-75/34 75 4.0 80 220 329
4030
4037 FS4874-100/35 100 5.5 90 220 379
4045 FS4874-130/35 130 7.5 110 240 429
4055 FS4874-180/07 180 11 110 240 438
4075 FS4874-300/99 300 15 300 564 160
4110
FS4874-400/99 400 22 300 564 160
4160
4185 FS4874-500/99 500 19.5 300 564 160
4220 FS4874-600/99 600 20.5 300 564 160
4300 FS4874-900/99 900 33.5 300 564 
160
Appendix
CE Conformance Information
