32 VG5 Installation & Quick-Start Manual
Wire and Terminal Screw Sizes
460V Class Wire Size
* Wire sizes are based on 75°C copper wire.
Circuit
Model
CIMR-
Terminal Symbol
Terminal
Screw
Wire Size *
Max. Torque
lb-in (N·m)
Wire Type
AWG mm
2
Main
VG5U40P4
L1, L2, L3, , 1, 2, B1, B2, T1, T2, T3
M4 14 - 10 2 - 5.5 12.4 (1.4)
Power cable:
600V vinyl
sheathed wire or
equivalent
VG5U40P7
L1, L2, L3, , 1, 2, B1, B2, T1, T2, T3
M4
14 - 10 2 - 5.5
12.4 (1.4)
12 - 10 3.5 - 5.5
VG5U41P5
L1, L2, L3, , 1, 2, B1, B2, T1, T2, T3
M4
14 - 10 2 - 5.5
12.4 (1.4)
12 - 10 3.5 - 5.5
VG5U42P2
L1, L2, L3, , 1, 2, B1, B2, T1, T2, T3
M4
14 - 10 2 - 5.5
12.4 (1.4)
12 - 10 3.5 - 5.5
VG5U43P7
L1, L2, L3, , 1, 2, B1, B2, T1, T2, T3
M4
14 - 10 2 - 5.5
12.4 (1.4)
12 - 10 3.5 - 5.5
VG5U44P0
L1, L2, L3, , 1, 2, B1, B2, T1, T2, T3
M4 12 - 10 3.5 - 5.5 12.4 (1.4)
VG5U45P5
L1, L2, L3, , 1, 2, B1, B2, T1, T2, T3
M4 12 - 10 3.5 - 5.5 12.4 (1.4)
VG5U47P5
L1, L2, L3, , 1, 2, B1, B2, T1, T2, T3
M5 8 - 6 8 - 14 22.1 (2.5)
VG5U4011
L1, L2, L3, , 1, 2, B1, B2, T1, T2, T3 M5 8 - 6 8 - 14 22.1 (2.5)
M6 8 8 45.1 (5.1)
VG5U4015
L1, L2, L3, , 1, 2, B1, B2, T1, T2, T3 M5 8 - 6 8 - 14 22.1 (2.5)
M6 8 8 45.1 (5.1)
VG5U4018
L1, L2, L3, , 1, 2, 3, T1, T2, T3 M6 6 14 45.1 (5.1)
M8 8 8 90.3 (10.2)
r, s M4 20 - 10 0.5 - 5 12.4 (1.4)
VG5U4022
L1, L2, L3, ,
1, 2, 3, T1, T2, T3 M6 4 22 45.1 (5.1)
M8 8 8 90.3 (10.2)
r, s M4 20 - 10 0.5 - 5 12.4 (1.4)
VG5U4030
L1, L2, L3, , 1, 2, 3, T1, T2, T3
M8
4 22
90.3 (10.2)
8 8
r, s M4 20 - 10 0.5 - 5 12.4 (1.4)
VG5U4037
L1, L2, L3, , 1, 2, 3, T1, T2, T3
M8
3 30
90.3 (10.2)
6 14
r, s M4 20 - 10 0.5 - 5 12.4 (1.4)
VG5U4045
L1, L2, L3, , 1, 2, 3, T1, T2, T3
M8
1 50
90.3 (10.2)
6 14
r, s M4 20 - 10 0.5 - 5 12.4 (1.4)
VG5U4055
L1, L2, L3, T1, T2, T3 M10 4/0 100 203.6 (23.0)
, , 3 M8 4 22 90.3 (10.2)
r, s200, s400 M4 20 - 10 0.5 - 5 12.4 (1.4)
VG5U4075
L1, L2, L3, T1, T2, T3 M10 1/0 x 2P 60 x 2P 203.6 (23.0)
, , 3 M8 4 22 90.3 (10.2)
r, s200, s400 M4 20 - 10 0.5 - 5 12.4 (1.4)
VG5U4110
L1, L2, L3, T1, T2, T3 M10 1/0 x 2P 60 x 2P 203.6 (23.0)
, , 3 M8 3 30 90.3 (10.2)
r, s200, s400 M4 20 - 10 0.5 - 5 12.4 (1.4)
VG5U4160
L1, L2, L3, T1, T2, T3 M12 4/0 x 2P 100 x 2P 349.6 (39.5)
, , 3 M8 1 50 90.3 (10.2)
r, s200, s400 M4 20 - 10 0.5 - 5 12.4 (1.4)
VG5U4185
L1, L2, L3, , 1, 3, T1, T2, T3 M16
650MCM x 2P 325 x 2P 867.4 (98.0)
M8 1 50 90.3 (10.2)
r, s200, s400 M4 20 - 10 0.5 - 5.5 12.4 (1.4)
VG5U4220
L1, L2, L3, , 1, 3, T1, T2, T3 M16 650MCM x 2P 325 x 2P 867.4 (98.0)
M8 1/0 60 90.3 (10.2)
r, s200, s400 M4 20 - 10 0.5 - 5.5 12.4 (1.4)
VG5U4300
L1, L2, L3, , 1, 3, T1, T2, T3 M16 650MCM x 2P 325 x 2P 867.4 (98.0)
M8 1/0 60 90.3 (10.2)
r, s200, s400 M4 20 - 10 0.5 - 5.5 12.4 (1.4)
Control
Common to
all
models
1-33 M3.5 20 - 16
Stranded
0.5 - 1.25
Solid
0.5 - 1.25
-
Twisted shielded
wire with Class 1
wiring
G M3.5 20 - 14 0.5 - 2 8.9 (1.0)
