Group d Reference
Function d1Preset Reference
D1-01
Frequency
Reference 1
(Reference 1)
0.00~
400.00
0.01Hz 0.00 — o Q Q Q Q
D1-02
Frequency
Reference 2
(Reference 2)
0.00~
400.00
0.01Hz 0.00 — o Q Q Q Q
D1-03
Frequency
Reference 3
(Reference 3)
0.00~
400.00
0.01Hz 0.00 — o Q Q Q Q
D1-04
Frequency
Reference 4
(Reference 4)
0.00~
400.00
0.01Hz 0.00 — o Q Q Q Q
D1-05
Frequency
Reference 5
(Reference 5)
000~
400.00
0.01Hz 0.00 — o B B B B
D1-06
Frequency
Reference 6
(Reference 6)
0.00~
400.00
0.01Hz 0.00 — o B B B B
D1-07
Frequency
Reference 7
(Reference 7)
0.00~
400.00
0.01Hz 0.00 — o B B B B
D1-08
Frequency
Reference 8
(Reference 8)
0.00~
400.00
0.01Hz 0.00 — o B B B B
D1-09
Jog Frequency
Reference
(Jog Reference)
0.00~
400.00
0.01Hz 6.00 — o Q Q Q Q
Function d2
Reference Limits
D2-01
Frequency Refer-
ence Upper Limit
(Ref Upper Limit)
0.0~110.0 0.1% 100.0 — x B B B B
D2-02
Frequency Refer-
ence Lower Limit
(Ref Lower Limit)
0.0~109.0 0.1% 0.0 — x B B B B
Function d3 Jump Frequencies
D3-01
Jump Frequency 1
(Jump Freq 1)
0.0~400.0 0.1Hz 0.0 — x B B B B
D3-02
Jump Frequency 2
(Jump Freq 2)
0.0~400.0 0.1Hz 0.0 — x B B B B
D3-03
Jump Frequency 3
(Jump Freq 3)
0.0~400.0 0.1Hz 0.0 — x B B B B
D3-04
Jump Frequency
Width
(Jump Bandwidth)
0.0~20.0 0.1Hz 1.0 — x B B B B
Function
Parameter
No.
Name
(Digital Operator
Display)
Setting
Range
Setting
Unit
Factory
Setting
Remarks
(Digital Operator Display)
Change
during
Operation
o: Enabled
x: Disabled
Parameter Access Level
User
Setting
V/f
V/f
w/
PG
Open
Loop
Vector
Flux
Vector
Appendix
VG5 Parameters
