88 VG5 Installation & Quick-Start Manual
Group E Motor
Function E1 V/F Pattern
E1-01
Input Voltage
Setting
(Input Voltage)
155~
255
(Note
13)
1 V
200
(Note
13)
¹When 02-09=1 [USA], the
value is 1.15 times of Japanese
spec., which is 230/200
x Q Q Q Q
E1-02
Motor Selection
(Motor Selection)
0, 1, 2 1 0
0: (Std Fan-Cooled)
1: (Std Blower-Cooled)
2: (Vector Motor)
<1110>
x Q Q Q Q
E1-03
V/f Pattern
Selection
(V/F Selection)
00~0F 1 0F
V/f pattern selection
0: 50Hz
1: 60Hz Saturation
2: 50Hz Saturation
3: 72Hz
4: 50Hz Variable Torque 1
5: 50Hz Variable Torque 1
6: 60Hz Variable Torque 1
7: 60Hz Variable Torque 2
8: 50Hz High Starting Torque 1
9: 50Hz High Starting Torque 2
A: 60Hz High Starting Torque 1
B: 60Hz High Starting Torque 2
C: 90Hz
D: 120Hz
E: 180Hz
F: User-defined V/f pattern
x Q Q Q Q
E1-04
Max. Output
Frequency
(Max Frequency)
40.0~40
0.0 0.1Hz
60.0*
(Note
13)
*Factory setting differs depend-
ing on the inverter capacity 02-
04.
When 02-09=2 [EUR.], the
value is 50.0Hz.
x Q Q Q Q
E1-05
Max. Voltage
(Max Voltage)
0.0~
255.0
(Note
13)
0.1 V
200.0
(Note
13)*
*Factory setting differs depend-
ing on the inverter capacity (02-
04).
When 02-09=1 (USA), the
value is 1.15 times of Japanese
spec., which is 230/200
x Q Q Q Q
Note 13: This value is for the 200V class. For 400V class, the value is twice that of 200V class. For 575V class, then modify the values by 575/200
Function
Parameter
No.
Name
(Digital Operator
Display)
Setting
Range
Setting
Unit
Factory
Setting
Remarks
(Digital Operator Display)
Change
during
Operation
o: Enabled
x: Disabled
Parameter Access Level
User
Setting
V/f
V/f
w/
PG
Open
Loop
Vector
Flux
Vector
Appendix
VG5 Parameters
