Group H Terminal Function
Function H4 Analog Outputs
H4-01
Monitor Selection
Terminal 21
(Terminal 21 Sel)
1~38 1 2
Analog output selection (terminal
21 (same as F4-01)
1: Frequency reference
2: Output frequency
3: Inverter output current
5: Motor speed
6: Output voltage
7: DC bus voltage
8: Output power
9: Torque reference (internal)
15: External terminal 13 input
voltage
16: External terminal 14 input
voltage
17: External terminal 16 input
voltage
18: Motor secondary current (Iq)
19: Motor excitation current (Id)
20: Primary frequency after SFS
21: Speed controller ASR input
22: Speed controller ASR output
23: Speed deviation
24: PID feedback
26: Voltage reference (Vq out-
put)
27: Voltage reference (Vd out-
put)
31: Not Used
32: ACR (q) Output
33: ACR (d) Output
36: PID Input
<1110>
37: PID Output <1110>
38: PID Reference <1110>
x B B B B
H4-02
Terminal 21 Output
Gain
(Terminal 21 Gain)
0.00~
2.50
0.01 1.00 — o B B B B
H4-03
Terminal 21Output
Bias
(Terminal 21 Bias)
–10.0~
+10.0
0.0% 0.0 — o B B B B
H4-04
Terminal 23
Monitor
(Terminal 23 Sel)
1~38 1 3
Analog output selection (terminal
23) (same as H4-01)
x B B B B
H4-05
Terminal 23 Output
Gain
(Terminal 23 Gain)
0.00~
2.50
0.01 0.50 — o B B B B
H4-06
Terminal 23 Output
Bias
(Terminal 23 Bias)
–10.0~
+10.0
0.1% 0.0 — o B B B B
H4-07
Analog Output
Signal Selection
(AO Level Select)
0, 1 1 0
0: (0 - +10 VDC)
1: (–10V +10 VDC)
x B B B B
Function
Parameter
No.
Name
(Digital Operator
Display)
Setting
Range
Setting
Unit
Factory
Setting
Remarks
(Digital Operator Display)
Change
during
Operation
o: Enabled
x: Disabled
Parameter Access Level
User
Setting
V/f
V/f
w/
PG
Open
Loop
Vector
Flux
Vector
